MHS Arto (Double Panel) (White)

£468.00 £1,963.00

Quantity

MHS Arto Double Panel Designer Radiator (White)

For installations that require larger outputs, while still retaining a bold design, the Arto Vertical offers supreme versatility with an extensive range of sizes.
Available in single and double versions.

MHS Arto Radiator Technical Details

Height........Width..........BTU.......Watts......Sections
1800mm.....224mm......2,252......660.........4
1800mm.....280mm..... 2,815......825..........5
1800mm.....336mm..... 3,378......990.........6

1800mm.....392mm......3,941......1,155........7
1800mm.....448mm..... 4,504.....1,320........8

1800mm.....504mm......5,067......1.485........9
1800mm.....560mm..... 5,630.....1,650.......10
1800mm.....616mm..... 6,193......1,815........11

1800mm.....672mm......6,756.....1,980........12
1800mm.....728mm..... 7,318......2,145........13

1800mm.....784mm......7,882.....2,310........14

2000mm.....224mm......2,457......720.........4
2000mm.....280mm..... 3,071......900.........5
2000mm.....336mm..... 3,685.....1,080.......6

2000mm.....392mm......4,299.....1,260.......7
2000mm.....448mm..... 4,913.....1,440.......8

2000mm.....504mm......5,527......1.620.......9
2000mm.....560mm..... 6,142......1,800......10
2000mm.....616mm..... 6,756.....1,980........11

2000mm.....672mm......7,370......2,160.......12
2000mm.....728mm..... 7,984.....2,340.......13

2000mm.....784mm......8,598.....2,520.......14

BTU/Watts calculated at Delta 50.

To convert to Delta 30, 2000mm x 784mm - Watts 1,285 & BTU 4,384 at Delta 30 (Conversion Factor 0.51)

Dry Weight - 2000 x 784 is 62.52 Kg and 21.83 Litres of water

Distance from wall to face 84mm (Vertical) & 118mm - 135mm (Horizontal)

Pipe to Pipe - Width plus valves (Vertical) & Width less 58mm (Underside)(Horizontal)

Wall to pipe - 55mm (Vertical) & 87 - 104mm (Horizontal)

PLEASE NOTE THE VERTICAL RADIATOR CANNOT BE PLACED HORIZONTALLY & VICE VERSA - The correct orientation MUST be placed at the time of order.

Colour - RAL 9016 Traffic White

High Quality Italian Design & Manufacturer

5 Year Manufacturers Guarantee

CE approved & certified to BS EN442

Radiator is supplied with brackets, bleed and blanking vent.

The MHS Arto various sizes and also as Single and Double configurations.

Please click here for MHS Arto Full Details

********************************

Buy with confidence as we are an approved MHS supplier - the MHS Arto Radiator comes with a 5 year manufacturers guarantee.

********************************
