MHS Arc (Double Panel) 600mm High (Colour Chart 1)

£446.00 £2,710.00

Quantity

MHS Arc Double Panel 600mm High Designer Radiator (Colour Chart 1)

The MHS Arc features elegant 50x25mm oval tubes that provide a contemporary and elegant finish – perfect for a wide range of interiors.

Featuring two sets of tubes, this radiator not only creates a more imposing profile, but also delivers increased outputs for larger rooms..

MHS Arc Radiator Technical Details

Height........Width..........BTU.......Watts
600mm.....300mm.......1189......349
600mm.....360mm..... .1427......418
600mm.....420mm..... 1665.......488

600mm.....480mm......1903.......558
600mm.....540mm..... .2140......627

600mm.....600mm.......2378......697
600mm.....660mm..... .2616......767
600mm.....720mm..... .2854......836

600mm.....780mm.......3092......906
600mm.....840mm..... .3329......976

600mm.....900mm.......3567.......1046
600mm.....1020mm.......4043.....1185

600mm.....1080mm......4281......1255
600mm.....1140mm..... 4519.......1324

600mm.....1200mm......4756.....1394
600mm.....1260mm..... 4994.....1464
600mm.....1320mm..... 5232.....1533

600mm.....1380mm......5470.....1603
600mm.....1440mm..... 5708.....1673

600mm.....1500mm..... 5945.....1743
600mm.....1560mm..... 6183.....1812

600mm.....1620mm......6421......1882
600mm.....1680mm..... 6659.....1952

600mm.....1740mm......6897......2021
600mm.....1800mm..... 7134......2091

BTU/Watts calculated at Delta 50.

To convert to Delta 30, 600mm x 1800mm - Watts 1,066 & BTU 3,638 at Delta 30 (Conversion Factor 0.51)

Dry Weight - 600 x 1800 is 45.84 Kg and 35.85 Litres of water

Distance from wall to face 95mm

Pipe to Pipe - Width plus valves

Wall to pipe - 55mm

Colour - Colour Chart 1

High Quality Italian Design & Manufacturer

5 Year Manufacturers Guarantee

CE approved & certified to BS EN442

Radiator is supplied with brackets, bleed and blanking vent.

The MHS Arc is also available in Heights of 800mm , 1000mm, 1200mm, 1400mm, 1600mm and 2000mm Single & Double Panel. Vertical image shows a single panel. Please email for prices relating to these configurations.

Please click here for MHS Arc Full Details

********************************

Buy with confidence as we are an approved MHS supplier - the MHS Arc Radiator comes with a 5 year manufacturers guarantee.

********************************

Why buy the MHS Arc 600mm High Designer Radiator from Hot Interiors?

* We ONLY sell radiators and associated products
* Expert Advice
* Authorised Retailer
* Super fast delivery on stock items
* Help available up to 10pm including Sunday!
* Low prices
* Informative and secure website
* Hundreds of happy customers
* Trading since 2006
